Detailed Product Description
Car Refrigerator Freezer for Camping, Fishing, Boat, Cars, Trucks, Yacht, ect
Features
1. We always use highly efficient and energy-saving DC compressor in our car refrigerator. This compressor ensures the car refrigerator with high reliability, energy saving, long service life and fast cooling speed;
2. Our machine can be used in the car (12V/24V), at home (110-220V power with an optional part of AC/DC adapter) and also outdoors where the machine is connected to 12V battery (optional part for a special wire) directly.
3. Our compressor cools the refrigerator as low as -20℃ rapidly (ambient temperature is 25 ℃);
4. Intelligent control system with power-off memory function is designed in the car refrigerator;
5. The special car battery intelligent protection system protects the car battery from breakage;
6. The unique power supply protection function protects the compressor from wrong button of the positive and negative;
Functions and Operations
Power supply and electrical: the refrigerator can be used for DC voltage 12V in the car [as photo 1, the car plug]; and can be connected to 12V/24V battery [as photo 2, the battery connector, which is selective part and to be paid separately]; and can be used at household AC 100-240V [as photo 3, as the power adapter, which is selective part and to be paid separately]. And there is extra battery for standby which is selective part and to be paid separately.
Photo 1 Photo 2 Photo 3
* Note: The car plug (photo 1) is included in the refrigerator. And the parts in photo 2, photo 3 and extra battery for standby are all selective parts to be paid separately.
The three voltage parameters as below:
H3 (high): 10.9V (stop) --12.2V (start voltage)
23.8V (stop) --25.2V (start voltage)
H2 (medium): 9.7V (stop) --11.0V (start voltage)
21.5V (stop) --22.9V (start voltage)
H1 (low): 9.6V (stop) --10.9V (start voltage)
21.3V (stop) --22.7V (start voltage)
Microcomputer control panel diagram:
Common temperature setting
• Red wine storage (10℃),
•Vaccine, Insulin (2℃- 8℃),
•Fruit (4℃- 6℃),
•Beverage (2℃-5℃),
•Meat (-10℃),
•Ice cream (-15℃);
Please be careful if you want to store drugs in the refrigerator.
Parameters Table
| Model | ZM-25D | ZM-30D | ZM-40D | ZM-50D |
| Capacity | 25L | 30L | 40L | 50L |
| Environment type | T/ST/N/SN | T/ST/N/SN | T/ST/N/SN | T/ST/N/SN |
| Safety level | III | III | III | III |
| Voltage | 12V/24V | 12V/24V | 12V/24V | 12V/24V |
| Rated current | 3.75/1.875A | 4.16/2.08A | 4.58/2.3A | 5.0/2.5A |
| Rated power | 45W | 50W | 55W | 60W |
| Refrigerant | R134a/35g | R134a/37g | R134a/39g | R134a/41g |
Detailed Specification table
| Product Name | DC Car Refrigerator (with trolley handle, LCD touch screen) |
| Model | ZM-50D |
| Climate Type | T ,ST,N,SN |
| Volume | 50L |
| Refrigerant | R134a |
| Voltage | DC12v/24v |
| Power | 60W | |
| Current | 3.7A/1.85A |
| Temperature(℃) as low as | -18 |
| Insulation Materials | C5H10/C-Pentane |
| N.W/G.W(Kgs) | 22KGS/24KGS |
| Product Size | 570*360*539mm |
| Carton Size | 639*424*604(mm) |
| Load Quantity | 20Ft | 40HQ |
| 180PCS | 396PCS |
